4
Subject to technical modications
without notice. © 2007
5
Small overlay top door hinge planning
CLIP top hinges
6
Large overlay top door hinge planning
COMPACT hinges
1-1/4”
1/8"
1/2
"
Part no.
CLIP top hinge
70T5580
Mounting plate
75H6000
Part no.
COMPACT hinge
3.4630
Mounting plate
30.30.0
Overlay table
13
*
14 15 16 17
3 3 4 5 6
B Bore distance
* Bore at 3 then adjust .
Assembly
Overlay table
1-1/4”
3
Bore distance
