LINCOLN SENTRY
Lift & Flap Systems
A.2
DRAWERS, HINGES & ASSEMBLY DEVICES
C.43
C
Drawers, Hinges & Assembly Devices
AVENTOS HF, HS, HL, HK
Assembly, removal and adjustment – SERVO-DRIVE
Blum transformer 72 W
Do not damage piercing tips
Blum transformer 72 W
Cable diagram
Cabling
Back (recommended)
Cabinet front edge to centre of hole
drilling:
HF: 167 mm
HS: 69 and/or 167 mm
HL: 74.5 and/or 167 mm
HK: 167 mm
Top (optional)
