BLUM AVENTOS HF User Manual

11
Subject to technical modifications without notice. © 2018
3
Removing the doors
1. Hold the bottom door while unclipping the bottom hinges.
2. Hold the top door while detaching the top hinges. Simply unclip them if using the CLIP top hinges
or loosen them if using COMPACT.
2
1
4
Removing the telescopic arms
Using a screwdriver, depress the release tabs to remove telescopic arms.
If transporting the cabinet to the jobsite, stop here. Lift mechanisms stay inside the cabinet for easy transport.
1
2
1
2

BLUM AVENTOS HF Specifications

General

Type	Bi-fold lift system
Cabinet Width	Up to 1800 mm
Soft Close	Yes
Adjustment	3-dimensional front adjustment
Application	Wall cabinet
Motion Technology	BLUMOTION, TIP-ON, SERVO-DRIVE
Material	Steel
Assembly	Tool-free assembly
Cabinet Height	480 mm to 1040 mm
Opening Angle	90°
