BLUM AVENTOS HF User Manual

Subject to technical modifications without notice. © 2018
10
Detaching the telescopic arms
1
2
Remove covers
WARNING
Release both arms and gently rest the top
door on the loose arms. The tension will hold
the doors up for the next step.
Warning: Risk of injury
from spring-loaded
telescopic arm!
Maintain control of telescopic arm while
releasing the CLIP mechanism.
Removal
Risk of injury from spring-loaded arm
▀ Do not push arm assembly down or leave in the down position
▀ Remove mechanism before installing or removing cabinet
1
2
1
2

BLUM AVENTOS HF Specifications

General

Type	Bi-fold lift system
Cabinet Width	Up to 1800 mm
Soft Close	Yes
Adjustment	3-dimensional front adjustment
Application	Wall cabinet
Motion Technology	BLUMOTION, TIP-ON, SERVO-DRIVE
Material	Steel
Assembly	Tool-free assembly
Cabinet Height	480 mm to 1040 mm
Opening Angle	90°
