BLUM AVENTOS HF User Manual

9
Subject to technical modifications without notice. © 2018
13
Attach covers
Attach the left and right cover plates to each lift mechanism then attach the symmetrical cover caps
Adjust and lock telescopic arms
12
1. Close and flush doors to cabinet. While pressing on
the top door, pull the bottom door open one inch.
1
2
2. Slightly open door and lock the telescopic arms
into position using the levers as shown.
Open door
enough to
lock levers

BLUM AVENTOS HF Specifications

General

Type	Bi-fold lift system
Cabinet Width	Up to 1800 mm
Soft Close	Yes
Adjustment	3-dimensional front adjustment
Application	Wall cabinet
Motion Technology	BLUMOTION, TIP-ON, SERVO-DRIVE
Material	Steel
Assembly	Tool-free assembly
Cabinet Height	480 mm to 1040 mm
Opening Angle	90°
