Subject to technical modifications without notice. © 2018
6
less than 6
12.5
19
12.5
ü
Standard mounting plate works
Attaching the telescopic arm mounting plate with bracket for five-piece doors
7b
more than 6
12.5
ü
Standard mounting plate does not work
Use mounting plate with bracket when
panel is
<
6 mm from screw
Part no.
175H3F00
Telescopic arm mounting plate with bracket
Assembly
