BLUM MINIPRESS M User Manual

9 BA-100/1EN M52.XXXX
F.1 - EC Declaration of Conformity
F - EC Declaration of Conformity / Techn. Data
F.2 - Technical data
1) General data
• Voltage: see serial tag
• Current: see serial tag
• Connected load
Motor: 1.1 kW
• RPM: see serial tag
Important: Provide a 16 A mains backup fuse.
3) Max. work piece thickness
• drilling only 45 mm
• Insertion
depending on the fitting max. 20 mm max. 32 mm
5) Max. drilling diameter
• Max. drilling diameter 45 mm
2) Weight and measurements
Weight: m= 37 kg
Dimensions: H= 966 mm
W= 600 mm
D= 531 mm
4) Max. drilling distance
• Drilling distance centre spindle: 0 - 70 mm
6) Accessories
• For accessories see BLUM complete catalogue
Julius Blum GmbH, Industriestr. 1, A-6973 Höchst herewith declare on our own responsibility that the product
MINIPRESS (M52.xxxx) with drilling heads (MZK.1000, MZK.1900, MZK.8000, MZK.8800) to which this Declaration refers, complies
with the following EC Directives:
EC Machine Directive 2006/42/EC
EC EMV Directive 2004/108/EC
The following harmonised European standards have been used to ensure proper implementation of the requirements specified in the
EU Directives:
EN ISO 12100-1, EN ISO 12100-2, EN 60204-1, EN 349
In addition, the following standards have also been applied:
EN ISO 11202, EN ISO 11204, DIN 33893-2
Registered location:
Fachausschuss Holz
Testing and certification centre in BG - PRÜFZERT
Postfach 800480
GS testing certification no.: 051140
BG testing certification no.: 051141
Hoechst, 06.07.09 Documentation authorised agent:
Dipl.-Ing. Herbert Blum Dipl.-Ing. (FH) Thomas Maier,
Managing Director www.blum.com
www.blum.com
