49
EN
1 Emergency button 14 Keyboard
2 The control panel cover 15 Charging electrode
3 Height of cut cover 16 Power connector
4 Rain sensor 17 Boundary connector
5 Charging socket 18 Charge station base
6 Front wheel 19 Operator’s manual
7 Blade plate 20 Power adapter
8 Blade 21 Nail for boundary wire
9 Rear wheel 22 Screws for charging station
10 Battery cover 23 Installation ruler
11 Handle 24 Spare blade
12 Cutting adjustment knob 25 Boundary wire
13 LCD display
