Blusafe Breeze - Breeze Model A Installation Guide; Model A Package Contents

20 pages

To Next Page

To Previous Page

Breeze Model A Smart Handle

A-External handle

E-Handle

mounting plate

F-Key G-Hollow spindle

I-Split bolt J-Self tapping screw K-Setting needle

H-Connection boss

B-Internal handle C-Latch D-Strike plate/cover

x 1 eachx 1x 1x 1

x 2

x 2 x 4

x 2 x 1

x 1

x 2

Package Contents

P-01

A External handle

E Handle mounting plate

F Key

G Hollow spindle

I Split bolt

J Self tapping screw

K Setting needle

B-1 Internal handle cover B-2 Battery cassette

H Connection boss

B Internal handle

C Latch

D Strike plate/cover
