Location screw1-A
Fig 1
P-02
Changing the Handle Direction
Fig 2 Fig 3
Spring end
Spring end
Spring end
Spring end
Locate the external handle (A), and hold it up to the external side of the door. Check that the handle
opens in the right direction. If it doesn't you will need to change the handle direction. If this needs
changing, it's likely that the internal one will too. Please follow the below instructions or watch the video
on our YouTube channel.
c
d
e
Look at the inside face of the handle, you will see a small location screw see Fig. 1. Push the
handle down slightly to relieve pressure and remove this location screw.
Rotate the handle 180 degrees so that it's pointing the other way. Ensure the spring arm doesn't
jump over the pillar that holds the location screw (see the spring ends in Fig. 2 and 3).
Pull the handle down slightly in its new position to relieve pressure and replace the location screw
back into its position.(You should start with either Fig. 2 or 3, then end up with the other one).
Repeat on the other handle.
Check that both handles now work in the correct direction for your door.
a
b
