C44-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk 02
Surge protection device
recommended
This product contains sensitive
electrical components that may be
damaged by electrical spikes, surges,
electric shock, lightning strikes, etc. Use
of surge protection systems is highly
recommended in order to protect and
extend the life of your equipment.
Safety And
Performance Notice
The transmission distances of HDMI
over UTP cables are measured using TE
CONNECTIVITY 1427071-6
EIA/TIA-568-B termination (T568B) of
cables is recommended for optimal
performance.
To minimise interference of the
unshielded twisted pairs in the
CAT5e/6 cable do not run the HDBaseT
/ Cat5e/6/6a cabling with or in close
parallel proximity to mains power
cables.
Do not substitute or use any other
power supply other than the enclosed
unit, or a Blustream approved
replacement.
Do not disassemble either the
Transmitter or Receiver units for
any reason. Doing so will void the
manufacturer’s warranty.
Contents
Thank you for purchasing
this product.
For optimum performance and safety,
please read these instructions carefully
before connecting, operating or
adjusting this product. Please keep this
manual for future reference.
Introduction 03
Features 03
Panel Descriptions 04
Control Ports 05
Matrix HDBaseT™ Receiver Options 06
Terminating HDBaseT™ CAT Cables 07
Understanding Matrix / RX Status Lights 07
Infrared Distribution 08
Infrared Remote Control 09
EDID Control 10
Example Schematic 11
Specifications 12
Package Contents 12
Maintenance 12
RS-232 and Telnet Commands 13-14
Infrared Commands 15-16
Web Browser Interface 17
PC Configuration Soware 17
Certifications 18
