BluStream C44CS User Manual

C66CS/C88CS USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk 20
RS-232 Configuration and Telnet Commands
COMMAND ACTION
? Print help information
HELP Print help information
STATUS Print system status and port status
INSTA Print All Inputs Status
OUTSTA Print All Outputs Status
CTRLSTA Print All Controls Status
PRESETSTATUS Print All Preset Configurations
PON Power On, system run on normal state
POFF Power O, system run on power save state
RESET Reset System To Default Setting
KEY ON/OFF Set system (front panel) KEY control On or O
NET IP
xxx.xxx.xxx.xxx
Set IP Address
NET GW
xxx.xxx.xxx.xxx
Set Gateway Address
NET SM
xxx.xxx.xxx.xxx
Set Subnet Mask Address
NET RB Set Network Reboot and Apply New Config
NET TN xxxx Set Telnet Port
NET DHCP ON/OFF Set Auto IP(DHCP) ON Or OFF
RS232BAUD z
Set RS232 Baud Rate To z
z = 1 2400, 2 4800, 3 9600, 4 19200, 5 38400, 6 57600
(default), 7 115200"
RS232OUT xx ON
Enable RS232 Remote-control Mode On HDBT
Output xx To Allow Matrix To Be Controlled From
Remote PC
COMMAND ACTION
RS232OUT
xx OFF
Disable RS232 Remote-control Mode On HDBT
Output xx To Allow Matrix To Be Controlled From
Remote PC
RS232ONOUT
xx y:z:a:b
When detecting a triggering signal, automatically
send y type of command a stored in slot x to the
third-party device whose baud rate is z On Output xx
xx = 00 : All Outputs
xx = [01-08] : Output 1 - 8
y = 1 Send RS232 display on
y = 2 Send RS232 display input select
y = 3 Send RS232 user command 1
y = 4 Send RS232 user command 2
z = a ASCII
z = h HEX
a = 1 2400
a = 2 4800
a = 3 9600
a = 4 19200
a = 5 38400
a = 6 57600 (default)
a = 7 115200
b = RS232 command
RS232OFFOUT
xx z:a:b
When a triggering signal is not detected, automati-
cally send y type of command a to the third-party
device whose baud rate is z On Output xx
xx = 00 : All Outputs
xx = [01-08] : Output 1 - 8
z = a ASCII
z = h HEX
a = 1 2400
a = 2 4800
a = 3 9600
a = 4 19200
a = 5 38400
a = 6 57600 (default)
a = 7 115200
b = RS232 command
RS232ONOUT
xx DISABLE
Disable Automatic RS232 Commands When Detect-
ing Signal On Output xx
xx = 00 : All Outputs
xx = [01-08] : Output 1 - 8
RS232OFFOUT
xx DISABLE
Disable Automatic RS232 Commands When Not
Detecting Signal On Output xx
xx = 00 : All Outputs
xx = [01-08] : Output 1 - 8
MXIR xx FR yy
Local Matrix IR Out xx From Remote Rx yy IR In
xx = [01-08] : Local IR Out 1 - 8
yy = [01-08] : Remote Rx IR In 1 - 8
yy = [00] : All Remote Rx IR In
IROUT xx ON
Enable IR Remote-control Mode On HDBT Output xx
To Allow Matrix To Be Controlled From Receiver IR
IROUT xx OFF
Disable IR Remote-control Mode On HDBT Output xx
To Allow Matrix To Be Controlled From Receiver IR
