C88CS QUICK REFERENCE GUIDE
Contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk
03
EDID Control
EDID (Extended Display Identification Data) is a data structure that is used between a display and a source. This data
is used by the source to find out what audio and video resolutions are supported by the display. By pre-determining
the video resolution and audio format of the source and display device you can reduce the time needed for EDID hand
shaking thus making switching quicker and more reliable.
Configuration of the EDID settings for each input can be achieved using the following RS-232 commands to specify the
required EDID:
EDIDxxDFzz
Where xx = Input: 00 refers to ALL inputs; 01-08 = specific input
zz = EDID as shown below
zz = 00: HDMI 1080p@60Hz, Audio 2ch PCM (Default)
01: HDMI 1080p@60Hz, Audio 5.1ch DTS/DOLBY
02: HDMI 1080p@60Hz, Audio 7.1ch DTS/DOLBY/HD
03: HDMI 1080i@60Hz, Audio 2ch PCM
04: HDMI 1080i@60Hz, Audio 5.1ch DTS/DOLBY
05: HDMI 1080i@60Hz, Audio 7.1ch DTS/DOLBY/HD
06: HDMI 1080p@60Hz/3D, Audio 2ch PCM
07: HDMI 1080p@60Hz/3D, Audio 5.1ch DTS/DOLBY
08: HDMI 1080p@60Hz/3D, Audio 7.1ch DTS/DOLBY/HD
09: HDMI 4K@30Hz 4:4:4, Audio 2ch PCM
10: HDMI 4K@30Hz 4:4:4, Audio 5.1ch DTS/DOLBY
11: HDMI 4K@30Hz 4:4:4, Audio 7.1ch DTS/DOLBY/HD
12: HDMI 4K@60Hz 4:2:0/4K@30Hz 4:4:4, Audio 2ch PCM
13: HDMI 4K@60Hz 4:2:0/4K@30Hz 4:4:4, Audio 5.1ch DTS/DOLBY
14: HDMI 4K@60Hz 4:2:0/4K@30Hz 4:4:4, Audio 7.1ch DTS/DOLBY/HD
15: HDMI 4K@60Hz 4:4:4, Audio 2ch PCM
16: HDMI 4K@60Hz 4:4:4, Audio 5.1ch DTS/DOLBY
17: HDMI 4K@60Hz 4:4:4, Audio 7.1ch DTS/DOLBY/HD
18: DVI 1280x1024@60Hz, Audio None
19: DVI 1920x1080@60Hz, Audio None
20: DVI 1920x1200@60Hz, Audio None
21: HDMI 1920x1200@60Hz, Audio 2ch PCM/6ch PCM
22: User EDID 1
23: User EDID 2
RS-232 Configuration
The RS-232 port is used for configuration and control of the product, as well as pass through of RS-232 commands to a
compatible Blustream HDBaseT™ receiver / matrix device.
The default RS-232 communication settings are:
Baud Rate: 57600
Data Bit: 8
Stop Bit: 1
Parity Bit: none
For a complete RS-232 command list please see the C88CS User Manual - available to download from the Blustream
website.
