CUSTOM PRO MATRIX USER MANUAL
Specifications
CUSTOMPRO-HUB Modular (8x8) Chassis
Audio Input Connections: 8 x 3.5mm stereo jack
RS-232 Serial Port: 1 x DB-9, female
TCP/IP Control: 1 x RJ45, female
Rack Mountable: 2U rack height, rack ears included
Casing Dimensions (W x D x H): 440mm x 283mm x 87mm,
without feet
Dimensions (W x D x H): 440mm x 291mm x 94mm, with feet
and connections
Shipping Weight:
5.5kg 5.5kg
Operating Temperature: 32°F to 104°F (0°C to 40°C)
Storage Temperature: -4°F to 140°F (-20°C to 60°C)
Power Supply: 1 x 24V/8A DC transformer to 4-pin DIN
CUSTOMPRO-HUB16 Modular (16x16) Chassis
Audio Input Connections: 16 x 3.5mm stereo jack
RS-232 Serial Port: 1 x DB-9, female
TCP/IP Control: 1 x RJ45, female
IR Input Connections: 17 x 3.5mm stereo jack
IR Output Connections: 17 x 3.5mm mono jack
Rack Mountable: 4U rack height, rack ears included
Casing Dimensions (W x D x H): 440mm x 422mm x 173mm,
without feet
Dimensions (W x D x H): 440mm x 430mm x 178mm, with feet
and connections
Shipping Weight:
11kg 11kg
Operating Temperature: 32°F to 104°F (0°C to 40°C)
Storage Temperature: -4°F to 140°F (-20°C to 60°C)
Power Supply: Internal 100-240V AC, IEC cables supplied
Maintenance
Clean this unit with a so, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit.
Package Contents
CUSTOMPRO-HUB
• 1 x CUSTOMPRO-HUB
(including Control Board)
• 1 x Rack Mounting Kit
• 1 x 24V/8A DC Power Supply & IEC power cabling
• 1 x Remote Control (REM88)
• 1 x Quick Reference Guide
CUSTOMPRO-HUB16
• 1 x CUSTOMPRO-HUB16
(including Control Boards, and IR Routing Boards)
• 1 x Rack Mounting Kit
• IEC Power Cabling
• 1 x Remote Control (REM16)
• 16 x IR Emitter (IRE1)
• 17 x IR Receiver (IRR)
• 17 x IR 3.5mm - 3.5mm Stereo to Mono, 12V to 5V
Control Cable (IRCAB)
• 1 x Quick Reference Guide
