CUSTOM PRO MATRIX USER MANUAL
Understanding the HDBaseT™ Status LED’s
The Custom Pro matrix and HDBaseT™ extender solutions include status LED indicators on the matrix, transmitter,
and receiver products to show all connections are active, and to help diagnose potential connectivity issues.
Understanding the Status Lights - Custom Pro Matrix:
• The yellow HDBaseT™ status link light will be OFF when the input / output has been turned o, PoC (Power over
Cable) has been turned o, or there is a problem with the specific matrix input / output
• The yellow HDBaseT™ status link light will BLINK when the input / output is on and working
• The green HDBaseT™ link light will BLINK if there is an unstable connection between the matrix and HDBaseT™
transmitter / receiver
• The green HDBaseT™ link light will be ON when a there is an active HDBaseT™ transmitter / receiver connected to
the matrix
• The green HDBaseT™ link light will be OFF when a there is no connection with a HDBaseT™ transmitter / receiver
Understanding the Status Lights - Blustream HDBaseT™ Transmitter / Receiver:
• The power link light will be OFF when no power is being received from either the matrix or from a local PSU
connected directly to the transmitter / receiver (Please Note: HDBaseT™ inputs of the Custom Pro matrix do not
supply PoC to Blustream HDBaseT™ transmitters)
• The power link light will be ON when power is being received from either the matrix or from a local PSU connected
directly to the transmitter / receiver
• The HDMI link light will be o when there is no connection with a source / repeater / display
• The HDMI link light will be ON when there is an active connection with a source / repeater / display (Please Note:
not all Blustream HDBaseT™ transmitters / receivers feature a HDMI status LED)
• The HDBaseT™ link light will be OFF when there is no CAT cable / active HDBaseT™ connection to the RJ45
HDBaseT™ input / output
• The HDBaseT™ link light will BLINK if there is an unstable connection between the matrix and HDBaseT™
transmitter / receiver
• The HDBaseT™ link light will be ON when a CAT cable is connected to the HDBaseT™ RJ45 input / output on the
matrix and an active connection is achieved with the Blustream HDBaseT™ transmitter / receiver
The link lights will only serve as an indication to the connectivity between matrix and remote transmitter and / or
receiver unit.
The LED’s will not indicate a termination, bandwidth, interference or cable length issue on a CAT cable run. Blustream
would always recommend qualifying / verifying / certifying a CAT cable run for suitability prior to the installation of
HDBaseT™ equipment.
