CUSTOM PRO MATRIX USER MANUAL
Example Schematic 16x16 Chassis
CAT Cable RS-232 HDMI Audio IR Cable
















Audio Source
Maximum of 16 4K Sources
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
In
Out
Both outputs from the same zone, HDMI and HDBT will output the same signal
1080p Display
4K Display
In
Out
Up To 70m Max
A B C D
HDMI IR Power over Cable RS-232
A
B C D
Control Processor
4K Projector
