Surge protection device
recommended
This product contains sensitive
electrical components that may be
damaged by electrical spikes, surges,
electric shock, lightning strikes, etc. Use
of surge protection systems is highly
recommended in order to protect and
extend the life of your equipment.
Safety And
Performance Notice
The transmission distances of HDMI
over UTP cables are measured using TE
CONNECTIVITY 1427071-6
EIA/TIA-568-B termination (T568B) of
cables is recommended for optimal
performance.
To minimise interference of the
unshielded twisted pairs in the CAT5e/6
cable do not run the HDBaseT /
Cat5e/6/6a cabling with or in close
parallel proximity to mains power
cables.
Do not substitute or use any other
power supply other than the enclosed
unit, or a Blustream approved
replacement.
Do not disassemble either the
Transmission or Receiver units for
any reason. Doing so will void the
manufacturer’s warranty.
Introduction 03
Features 03
Panel Descriptions 04
Control Ports 05
HDBaseT Receiver Options 06
Matrix Front Panel Controls 07
Terminating HDBaseT CAT Cables 08
Understanding Matrix/RX Status Lights 08
Infrared Distribution 09
Infrared Remote Control 10
EDID Control 11
Application Diagram 12
Specifications 13
Package Contents 13
Maintenance 13
RS-232 and Telnet Commands 14-15
Infrared Commands 16-18
Web Browser Interface 19
PC Configuration Soware 19
Contents
Thank you for purchasing
this product.
For optimum performance and safety,
please read these instructions care-
fully before connecting, operating or
adjusting this product. Please keep this
manual for future reference.
TL to update when manual complete

BluStream HEX100ARC-KIT V2 Specifications

General

Brand	BluStream
Model	HEX100ARC-KIT V2
Category	Extender
Language	English
