HEX100ARC-KIT V2 USER MANUAL
Our Platinum Range of HDBaseT products oer the very best in performance
and flexibility. The HEX100ARC extender set is an industry leading 4K
HDBaseT solution delivering HDMI with HDCP 2.2 support, Bi-directional IR,
RS232 and PoH (PoE) up to lengths of 100m over a single CAT cable. The
HEX100ARC also provides enhanced features including HDMI loop-out on
the Transmitter, ARC via HDMI or Optical (S/PDIF) and an integrated 3-port
ethernet switch.
Introduction
FEATURES:
• Advanced HDBaseT technology oering uncompressed video and audio with zero latency
• Extends HDMI up to a distance of 100m over single CAT cable
• Supports 4K UHD video up to 70m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz
4:2:0)
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports 3D signal display
• Features 1x HDMI loop out for integrating local displays or cascading to multiple devices
• Supports ARC (Audio Return Channel) from display via HDMI and Optical digital inputs (ARC feature
supports distance of up to 90m)
• Supports audio return to HDMI, Optical digital and analogue L/R audio outputs (DAC PCM only)
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and
DTS-HD Master Audio transmission
• Integrated 3-port ethernet switch (LAN Serving)
• Bi-directional RS-232 pass through
• Bi-directional IR from all input and output locations
• Supplied with Blustream IR receiver and emitter
• Bi-directional PoH (Power over HDBaseT) to power extenders from either transmitter or receiverend
• HDCP 2.2 support
