BluStream Multicast ACM200 Api Documentation

ACM200 API DEVELOPMENT
05
contact support@blustream.co.uk / support@blustream.com.au
Application Diagram - RS-232 or TCP/IP Control
Example Schematic EX40B-Kit
RS-232 LAN Cable
IR Cable
Example Schematic ACM200
IO Level
Reset
VOut
IO4
IO3
IO2
IO1
5V Normal
RS-232
MCU
12V
ACM200
Video LAN(PoE)
Control LAN
IR Ctrl
IR
5V
12V
DC 12V
Power
Link Link
PoE
Yellow Green Yellow Green
Reserved for future update
Control Processor
Optional 12V PSU where no PoE is available
Multicast UHD
Network Switch
Customer Home / Business
Network Switch
1G Managed Network Switch 1G Managed Network Switch

BluStream Multicast ACM200 Specifications

General

Brand	BluStream
Model	Multicast ACM200
Category	Control Unit
Language	English
