SC11HD-V2 USER MANUAL
06
www.blustream.co.uk
Example Schematic
SC11HD-V2
HDMI
Coaxial Digital Cable
Speaker Cable
Analogue Audio Cable
4K SOURCE
Non 4K Display
Down-scaled
video output
HDMI Output L/R Out Upgrade
Coaxial
Out
Link
Mode
3 2 1
1
0
0
DC 5V
L/R In
HDMI Input EDID
Power
Link
3 2 1
1
0
0
