BluStream SC11HD-V2 User Manual

SC11HD-V2 USER MANUAL
05
contact support@blustream.co.uk / support@blustream.com.au
3 2 1 0
EDID Type
Combination of DIP positions
0 0 0 0 Copy EDID from output
0 0 0 1 1080p 2.0ch
0 0 1 0 1080p 5.1ch
0 0 1 1 1080p 7.1ch
0 1 0 0 1080i 2.0ch
0 1 0 1 1080i 5.1ch
0 1 1 0 1080i 7.1ch
0 1 1 1 4K60Hz 4:2:0 2.0CH
1 0 0 0 4K60Hz 4:2:0 5.1CH,
1 0 0 1 4K60Hz 4:2:0 7.1CH
1 0 1 0 4K30Hz 4:4:4 2.0CH
1 0 1 1 4K30Hz 4:4:4 5.1CH
1 1 0 0 4K30Hz 4:4:4 7.1CH
1 1 0 1 DVI 1280x1024
1 1 1 0 DVI 1920x1080
1 1 1 1 DVI 1920x1200
EDID Management
EDID (Extended Display Identification Data) is a data
structure that is used between a display and a source.
This data is used by the source to find out what audio
and video resolutions are supported by the display then
from this information the source will determine what
the best resolution is to output.
While the objective of EDID is to make connecting
a digital display to a source a simple plug and play
procedure issues do arise when multiple displays or
video matrix switching is introduced because of the
increased number of variables.
The SC11HD-V2 will act as an ‘end point’ in the HDMI
signal path. Using the EDID dip-switches pre-determins
the video resolution and audio format of the source
regardless of the video output resolution that the
SC11HD-V2 scales to.
To change the EDID settings move the EDID dip-
switches as required on the front panel of the unit.
Please see adjacent table for settings.
Note: You must power-cycle the SC11HD-V2 aer
changes have been made in order for the EDID settings
to update.
3 2 1 0
Mode Settings
Combination of DIP positions
1 x x 0 Always convert 4K formats to 1080P
0 x x 0 Auto convert 4K formats to 1080P when the device detects the display cannot support 4K
x 1 x 0 HDCP follows the source device
x 0 x 0 HDCP follows the display device
x x 1 0 Audio embed mode - embeds the analogue le/right audio onto the HDMI signal
x x 0 0 Audio bypass mode - allows HDMI audio to pass through
x x x 1 Mode control by serial USB
x x x 0 Mode control by DIP switch
Note: You must power-cycle the SC11HD-V2 aer changes have been made in order for the Mode settings to update.
The SC11HD-V2 cannot up-scale to 4K video formats.
Mode Management
