BMC G2S A20 User Manual

G2S A20 / G2S C20 User Manual V1.0
6 / 39
Sound Pressure Level
＜28 dB, when the device is working at the pressure of 10 hPa.
Sound Power Level
＜38 dB, when the device is working at the pressure of 10 hPa.
Maximum Flow
Test Pressures (hPa)
4
10
15
20
Measured Pressure at the
Patient Connection Port (hPa)
3
9
14
19
Average Flow at the Patient
Connection Port (L/min)
85
135
140
140
Automatic leak compensation
The pressure error ≤ ± 1 hPa when the air leakage is no more than 70 L / min.
Pressure
Range: 0 ～ 20 hPa
Margin of Error: ± (0.4 hPa + 4%)
Tube
Length: 6 ft. (1.83 m)
Maximum Delivered Gas Temperature
≤43°C
The Form and the Dimensions of the Patient Connection Port
The 22 mm conical air outlet complies with ISO 5356-1.

BMC G2S A20 Specifications

General

Brand	BMC
Model	G2S A20
Category	Medical Equipment
Language	English
