BMC ICS AERO 30000749 User Manual

CLIP-ON EXTENSIONS
NUMBER PART
1
LEFT Upper Clamp
Marked As “L” On The Inner Face
2
LEFT Lower Clamp
Marked As “L” On The Inner Face
3 LEFT Extension Body
4 Extension Clamps
5 M5 X 25 (incl 5x8.5mm Washer)
6 M4x12 (incl. 4x7mm Washer)
7 M4x20 (incl. 4x7mm Washer)
8
RIGHT Upper Clamp
Marked As “R” On The Inner Face
9
RIGHT Lower Clamp
Marked As “R” On The Inner Face
10 RIGHT Extension Body
11 Assembly Guide (remove after assembly)
12
Assembly Guide Bolts (M6 X 12)
And O-ring 5.6x1.8
13 Arm Rests
14 Arm Pads
15 M6 Bolt M6 X12
16 Carbon Extensions
PART LIST
Item Number: 30000749
1
2
3
4
5
6
7
7
8
9
10
11
12
13
14
15
16
ICS AERO CLIP-ON EXTENSIONS Quick Guide
