BMPRO Genius Series - Page 13

13
11
Figure 3: DC Wiring Diagram
Caravan
Battery
–
+
12V
FUSE
+
Load 1
–
Optional Switch
Close to disconnect
all Loads
Fuse for Caravan
Battery/Solar
Regulator
+
Load 10
–
. . . . . . . .
Fuse 1
Fuse 2
Fuse 3
Fuse 4
Fuse 5
Fuse 6
Fuse 7
Fuse 8
Fuse 9
Fuse 10
Fuses for Loads
+
–
12V
Solar
Regulator
Car Battery
or other DC
source
–
+
12V
10A
10A
10A
10A
10A
10A
10A
10A
10A
10A
35A
The solar regulator may be connected at the Genius-II or at the caravan battery as shown above.
Figure 3: DC Wiring Diagram
