BMPRO Genius Series - Specifications; Repairs and After-Sales Service

22
Input Voltage
240 Vac nominal, ±10%, 50/60 Hz. The power supply will
withstand a 5 min +15 % surge on the maximum nominal voltage
Input Surge < 40 A (cold start)
Holdup Time
< 10 mS at full load current and over nominal input voltage
operating range
Output Current 35 A Continuous (load + battery current)
Factory Set Voltage 13.65 V +/0.1 V (Float voltage)
Load Regulation < 2 %
Output Ripple Voltage < 150 mV
Over Voltage Protection < 17 V
Over Current Protection 35 A to 38 A (load + battery current)
Battery Current Limit
15 A ± 1 A (GENIUS-II, GENIUS-IIA and GENIUS-IIN)
30 A ± 3 A (GENIUS-IIH, GENIUS-IIHA and GENIUS-IIHN)
Battery Connect 11.5 ± 0.2 V
Disconnect 10.0 ± 0.2 V
Battery Drain < 3 mA
Efficiency > 84 %
Cooling Fan Thermally controlled
Ambient 0°C – 50°C
Weight 3.7 kg
Standards
Safety: AS/NZS 60335.1, AS/NZS 60335.2.29 | EMC: AS/NZS
CISPR 22 Class A | Compliance: ERAC
SPECIFICATIONS
REPAIRS AND AFTER-SALES SERVICE
Please consult your BMPRO dealer.
WARNING
Do not disassemble, modify, or repair the unit.
Doing so may result in electric shocks or fire.
