G650 Continued..
Remove the centre trim panel.
Remove the following components:
• Oil-tank cap (1)
• Screws (2)
• Screws (3)
• Centre trim panel (4)
• Install oil-tank cap (1)
Disengage large heat shield from the battery (1)
• Push back cover 1 of the battery's positive terminal.
• Begin by connecting one end of the red jump lead to positive terminal 2 of the
discharged battery and the other end to the positive terminal of the donor battery.
• Then connect one end of the black jump lead to the negative terminal of the donor
battery and the other end to negative terminal of the discharged battery.
