Heating and ventilation/Air conditioner
1 Air onto the windshield and the side
windows
2 Airflow for the upper body
The rotary dials make it possible for
you to open and close the air supply
through an infinitely-variable range,
while the levers change the airflow
direction. Refer to page 75
3 Front footwell ventilation
4 Air supply
Both the heating and ventilation are
available from position 1 on. Refer to
page 74
5 Defrost windows and remove
condensation 75
6 Temperature 74
7 Air distribution toward
> the windows
> the upper body
> the footwell
An infinitely-variable range of inter-
mediate settings is also available.
Refer to page 74
8 Rear window defroster with the
hardtop in place 75
9 Operating:
> Recirculated air 74
> Incoming air 74
> Air conditioner/Incoming air 74
> Air conditioner/Recirculated air 74
