Rear center console
Remove the cover.
In the cargo area
To access the socket: fold open the cover.
Cargo area
Trunk cover
Note
Do not deposit heavy objects
Do not deposit heavy or hard objects on
the
trunk cover. Otherwise, they could endanger
occupants during braking and evasive maneu‐
vers, for example.◀
Removing
To load bulky luggage, the cover can be re‐
moved.
1. Place your hands into the two recessed
grips on the bottom of the cover.
2. Push up the cover.
The cover can be stowed in the rear cargo area
floor compartment, refer to page 142.
Installing
1. Insert the trunk cover into the two front re‐
taining pins.
2. Fold down the cover until it engages.
Through-loading system
General information
The cargo area can be expanded by folding
down
the cargo partition and the rear seat back‐
rest.
Seite 136
136
Online Edition for Part no. 01 40 2 606 445 - 03 11 490
Interior equipment
