Pin Assignments
03/00
BM
BMW
BMWBMW
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionType
60 E Programming voltage Data link connector
61 M Oxygen sensor heating ground Oxygen sensor (behind catalytic converter)
62 A Activate valve Secondary air pump value
63 E Cyl. 4-6 knock sensor Knock sensor
64 M Ground Camshaft position sensor
65 E Camshaft position Camshaft position sensor
66 Not used
67 M Oxygen sensor signal ground Oxygen sensor (in front of catalytic
converter)
68 A Activate valve Evaporative emission valve
69 A Activate relay Fuel pump relay
70 M Oxygen sensor signal ground Oxygen sensor (in front of catalytic
converter)
71 M Oxygen sensor signal ground Oxygen sensor (behind catalytic converter)
72 M Oxygen sensor signal ground Oxygen sensor (behind catalytic converter)
73 E Activate relay Engine control module relay
74 A Activate A/C compressor Compressor control relay
75 E Sensor signal Oxygen sensor (in front of catalytic
converter)
76 E Sensor signal Oxygen sensor (in front of catalytic
converter)
77 E Sensor signal Oxygen sensor (behind catalytic converter)
78 E Sensor signal Oxygen sensor (behind catalytic converter)
79 M Oxygen sensor heating ground Oxygen sensor (behind catalytic converter)
80 A ASC signal ZA Slip control module ABS/ASC
81 A ASC signal ZWV Slip control module ABS/ASC
82 A ASC signal MSR Slip control module ABS/ASC
83 E Sensor signal Crankshaft position/RPM sensor
84 Not used
85 E/A CAN LOW Transmission control module EGS
86 E/A CAN HIGH Transmission control module EGS
87 E Battery voltage, terminal 87 Engine control module relay
88 E/A TxD diagnosis data link Data link connector
To Next Page
