BMW E36 Coupe - Page 93

ENGINE CONTROL SYSTEM MS41.1 (6–CYLINDER M52)
Y6120
EVAPORATIVE
EMISSION VALVE
.5 RT/WS
2
X6120
1 X6120
03/00
1210.17Ć
1999
01
A6000
ENGINE CONTROL
MODULE (DME)
.5 BR
Y6106
CYL. 6 FUEL
INJECTION VALVE
–
+
–
+
Y6101
CYL. 1 FUEL
INJECTION VALVE
–
+
Y6102
CYL. 2 FUEL
INJECTION VALVE
–
+
Y6103
CYL. 3 FUEL
INJECTION VALVE
–
+
Y6104
CYL. 4 FUEL
INJECTION VALVE
–
+
Y6105
CYL. 5 FUEL
INJECTION VALVE
–
+
27
1
68 6 5 22 24 23 X6000
.5 RT/WS
1 X6101
1 X6103
.5 RT/WS
1
X6105
1 X6106
.5 RT/WS
1 X6104
.5 RT/WS
1 X6102
.5 RT/WS1 RT/WS
2 X6130
2 X6102
2 X6104 2 X6106
2
X6105
2 X6103
2
X6101
.75 BR/WS .75 BR/RT .75 BR/GE .75 BR/BL .75 BR/GN .75 BR/VI
X6130
Y6130
IDLE SPEED
CONTROL VALVE
X6820
.5 RT/WS
1210.17-00
1.5 RT/WS
1210.17-00
33
.5 WS/
GN
3
.5 WS/
GE
53
1210.17-05
.5 RT/WS
31 31 31 31 31 31 31
31
