34
E46iCCVM/ST039/3/21/00
The hard top locks on the left and right, in the rear, have integrated wiring connectors for
power and ground supplies to the rear window defogger and interior lights.
The connector on the left side contains two
separate strips, one for power supply to the rear
defogger and the other for power supply to the
interior lights
The connector on the right side contains two
separate strips, one for the ground connection
for the rear defogger and the other for
Ground &
GM V control
Power &
GM V control
ART-HARDTOPLOCKLEFT
ART-HARDTOPCONN
ART-KT5260
ART-HARDTOP2
ART-HARDTOP2
