Schematic for Antenna Systems
34
E93 Complete Vehicle Workbook
Index Explanation
1
Car Access System
2
Remote control receiver in interior rear view mirror
3
CCC
4
Junction box
5
Rejector circuit, negative
6
FM3 antenna with amplifier in right hand shoulder trim
7
Comfort Access
8
Convertible Top Module
9
FM2 antenna in bumper
10
FM4 antenna in bumper
11
FM antenna diversity module
12
AM/FM1 antenna with amplifier in left hand shoulder trim
13
AM/FM antenna amplifier in rear window
14
Rejector circuit, positive
