BMW F 650 CS Repair Manual

00.8
Model F 650 CS
Connection
33 Rear wheel drive
Suspension strut to frame Nm 58
Wrench angle ° 45 ± 15
Suspension strut to angled lever Nm 41
Swinging-fork pivot axle Nm 100
Struts to swinging arm Nm 41
Struts to angled lever Nm 41
Angled lever to frame Nm 58
Wrench angle ° 45 ± 15
Belt pulley to damper housing Nm 28
Damper fastener Nm 160
Eccentric clamp Nm 21
Initial tightening Nm 10
Model F 650 CS
Connection
34 Brakes
Bleed screw to brake caliper front/rear Nm 7
Brake caliper to fork slider tube Nm 41
Brake light switch to handlebar fitting Nm 3
Handlebar fitting to handlebar Nm 9
Brake light switch to frame Nm 5
Brake disc to front wheel Nm 10
(clean thread + Loctite 2701)
Brake disc to rear wheel drive shaft Nm 11
(clean thread + Loctite 2701)
Brake caliper to swinging arm Nm 21
Brake master cylinder to main frame Nm 10
Locknut for fork end to pushrod Nm 9
Bracket, rear, to main frame Nm 9
(clean thread + Loctite 2701)
Shroud to frame Nm 6
Brake fluid reservoir for rear brake to rear
frame
Nm 4
Brake pedal to frame Nm 21
Brake line distributor to main frame Nm 9

BMW F 650 CS Specifications

General

Displacement	652 cc
Bore x Stroke	100 mm x 83 mm
Compression Ratio	11.5:1
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Seat Height	780 mm (30.7 in)
Engine Type	4-stroke, single cylinder
Power	50 hp (37 kW) @ 6, 500 rpm
Fuel System	Fuel injection
Front Brakes	Single disc
Rear Brakes	Single disc
Fuel Capacity	15 liters (4.0 US gal)
