Index Explanation Index Explanation
1
Central gateway module
12
USB hub
2
Instrument cluster
13
Not for US
3
Steering column switch cluster
14
Roof antenna
4
Central information display
15
ULF-SBX-High (6FL)
5
Car Information Computer
16
Rear power distribution box
6
Junction box
K-CAN
Body CAN
7
Microphone, left side of vehicle
PT-CAN
Powertrain CAN
8
Controller
FlexRay
FlexRay bus system
9
AUX-In connection combined for USB
connection + jack plug
MOST
Media Orientated System Transport
10
Microphone, right side of vehicle
LVDS
Low voltage differential signal
11
Bluetooth antenna
12
Antenna diversity
