G01�General�Vehicle�Electronics
2.�Interior�Lighting
21
Index Explanation
1 Footwell�light,�front�left
2 Ambient�lighting,�instrument�panel,�passenger's�side
3 Footwell�light,�front�right
4 Glove�box�switch
5 Glove�box�light
6 Fuses�in�the�power�distribution�box,�front�right
7 Body�Domain�Controller�(BDC)
8 Lighting�for�door�storage�compartment,�passenger's�side
9 Door�trim�panel�lighting,�passenger's�side
10 Door�entry�light,�front�passenger's�side
11 Door�contact,�front�passenger�side,�front
12 Door�contour�lighting,�passenger's�side
13 Lighting�for�door�storage�compartment,�passenger's�side�rear
14 Door�trim�panel�lighting,�passenger's�side�rear
15 Door�entry�lighting�passenger's�side,�rear
16 Door�contact�on�front�passenger�side,�rear
17 Door�contour�lighting,�passenger's�side�rear
18 Fuse�for�rear�right�power�distribution�box
19 Luggage�compartment�light,�right
20 Tailgate�contact�switch�in�the�tailgate�lock
21 Tailgate�lighting
22 Luggage�compartment�light,�left
23 Door�contour�lighting,�driver's�side�rear
24 Door�contact�on�driver's�side,�rear
25 Door�entry�lighting�driver's�side,�rear
26 Door�storage�compartment�lighting,�driver’s�side�rear
27 Door�trim�panel�lighting,�driver’s�side�rear
28 Door�contour�lighting,�driver's�side
29 Door�contact,�driver's�side,�front
30 Door�entry�light,�front�driver's�side
31 Door�trim�panel�lighting,�driver’s�side
32 Door�storage�compartment�lighting,�driver’s�side
33 Lighting,�center�stack
34 Lighting,�center�console
35 Interior�light,�rear�right�(on�vehicles�with�panorama�glass�roof)
