BMW K1600GTL User Manual

the engine is at operating
temperature.
Make sure the ground is level
and firm and with the engine
at operating temperature, place
the motorcycle on its centre
stand.
Allow the engine to idle until
the fan starts up, then allow it
to idle one minute longer.
Switch off the engine and wait
for about one minute to allow
the oil to drain into the sump.
Wipe the area around the oil
filler neck clean.
Remove oil dipstick 1 and wipe
it with a clean, dry cloth.
Seat the oil dipstick on the oil
filler neck, but do not engage
the threads.
Remove the oil dipstick and
check the oil level.
Engine oil, specified level
Between MIN and MAX marks
(Engine at regular operating
temperature)
Engine oil, quantity for
topping up
max 0.5 l (Difference between
MIN and MAX)
If the oil level is below the MIN
mark:
Top up the engine oil ( 132).
8
131
z Maintenance

BMW K1600GTL Specifications

General

Displacement	1649 cc
ABS	Standard
Traction Control	Standard
Suspension Front	BMW Motorrad Duolever
Suspension Rear	BMW Motorrad Paralever
Tires Front	120/70 ZR 17
Tires Rear	190/55 ZR 17
Engine Type	Oil/water-cooled, six-cylinder, four-stroke, in-line engine
Power	118 kW (160 hp) at 7, 750 rpm
Torque	175 Nm at 5250 rpm
Transmission	6-speed
Fuel Capacity	26.5 liters
Seat Height	750 mm
Brakes Front	Dual 320 mm discs, 4-piston calipers
Brakes Rear	Single 320 mm disc, 2-piston caliper
Weight	358 kg (unladen weight, road ready, fully fueled)
