BMW M COUPE 2002 Electrical Troubleshooting Manual

BMW
BMW
BMW
6211.0Ćc
2001
Pin Assignments
01/01
BM
BMW
BMWBMW
Z3
E = Input, A = Output, M = Ground
X271
Pin Type Description/Function Connection
1 A Fuel level sensor Fuel tank sensors
2 Not used
3 A Ground supply for fuel tank sensor and
vehicle speed sensor
Fuel tank sensor and vehicle speed
sensor
4 E Position signal (TW) Vehicle speed sensor
5 Not used
6 E A/C-ON-signal Air condition switch
7 E Activate A/C Pressure switch
8 Not used
9 E Oil level signal Thermal oil level sensor (TOENS) control
module (Z3 Versions)
Engine control module (DME) (M Versions)
10 Not used
11 Not used
12 Not used
