Assisted Driving Plus, refer to page 235.
White lights
Extended Traffic Jam Assistant
Indicator light is illuminated: the system
is ready.
Additional information:
Assisted Driving Plus, refer to page 235.
Fuel gauge
Concept
The current fill level of the fuel tank is displayed.
General information
Vehicle tilt position may cause the display to
vary.
Additional information:
Refueling, refer to page 314.
Display
Instrument cluster with enhanced features:
An arrow beside the fuel pump
symbol shows which side of the
vehicle the fuel filler flap is on.
The current range is displayed as
numerical value.
Instrument cluster without enhanced features:
An arrow beside the fuel pump
symbol shows which side of the
vehicle the fuel filler flap is on.
Indicator light in the instrument
cluster
The yellow indicator light illuminates,
once the fuel reserve is reached.
Tachometer
General information
Always avoid engine speeds in the red warning
field. In this range, the fuel supply is reduced to
protect the engine.
Instrument cluster with
enhanced features: Activating/
deactivating
1.
"CAR"
2. "Settings"
3. "Displays"
4. "Instrument panel"
5. "Engine display"
6. "Tachometer"
When the setting for the drive mode view is acti‐
vated, the activated tachometer is only shown in
the COMFORT or SPORT drive mode.
Instrument cluster with
extended features: Power
rating
Concept
The display indicates the performance POWER
as a percentage of its total power. In the
CHARGE range, the energy recovery is displayed
when coasting or decelerating.
General information
The available power may be reduced due to cer‐
tain factors, for instance a cold engine.
Seite 155
Displays
CONTROLS
155
Online Edition for Part no. 01405A111C1 - VI/20
