158n
Lamps and bulbs
Turn signal indicator/Side lamps
(side marker lamps), front
Dual-filament bulb, 21 watts
1 Turn the bulb holder to the left and
remove it.
2 Remove and replace the bulb.
390de670
Side turn signals*
5 watt bulb
1 Use finger pressure against the rear
end of the lens (arrow) to press it
forward for removal.
1 Apply gentle pressure to the bulb
while turning it to the left to remove.
390de106
Front fog lamps
HB4, 51 watt bulb
The bulb is pressurized. There-
fore, wear safety glasses and pro-
tective gloves. Failure to comply with
this precaution could lead to injury if the
bulb is accidentally damaged during
replacement.<
1 Pull the cover panel next to the fog
lamp forward to remove.
2 Loosen the screw (arrow) and swing
the lamp assembly out.
3 Release the spring on the back of the
lamp and turn the cover to the left.
4 Release the clamp, remove the
contact base and replace the bulb.
