Multi-Information Display (MID)
Central display
The MID serves as the central display
and control for the following onboard
systems:
> Digital clock (e.g. time displayed in
digital numerals, date)
> Audio-systems (radio, cassette, CD)
> Computer (e.g. fuel consumption,
cruising range)
> Cellular phone (e.g. dialing)
You will find explanations and notes for
operating the digital clock and the
computer on the following pages.
Please refer to the separate Owner's
Manual on operating the audio-
systems, the cellular phone and the
onboard monitor.
Any unrealistic number entries will
not be accepted.
All stored data will be lost if the power
supply is interrupted. Time of day,
switch-on times for independent
heating and ventilation, distance and
cruise control speed limit must be
reset, once the power supply has been
re-established.<
1 Function button for sound systems
2 Function button for the cellular
phone
*
3 Indicator lamp for independent
ventilation system
> remains on if switch-on time is
active
> flashes while operating
4 Function button for the digital clock
and computer
5 Indicator display for the various
computer systems
390us705
6 Display for the entry and check
buttons. Depending on the operating
mode, the functions and alternatives
which can be selected via the keys
are displayed here
7 Entry and check buttons for
operating the various computer
systems
