170n
Manual release
1 Use the handle to lower the trim
panel on the right side of the luggage
compartment.
2 Pull the knob with the fuel pump
symbol (arrow).
394de679
Manual operation
1 Remove the interior lamp (refer to
page 160), reach into the opening
and push out the panel.
2 Use the Allen wrench from the
onboard tool kit (refer to page 156) to
turn the sliding/tilt sunroof in the
desired direction.
390de376
Fuel filler door Sliding/Tilt sunroof*
