127n
OverviewControlsMaintenanceRepairsDataIndex
Lamps and bulbs
1. Use the upper handle to fold down
the side panel in the luggage
compartment
2. Turn the corresponding bulb holder
to the left (arrow) and remove it
3. Press the defective bulb gently and
turn it to the left. Remove the bulb
and replace it
4. Insert the bulb holder and turn to the
right as far as possible.
394de769
Center (high-mount) brake lamp
21 watt bulb
1. Open the luggage compartment lid
2. Use a screwdriver to unclip the cover
panel (on the underside of the
storage tray) (arrow)
3. Turn the bulb holder to the left and
remove
4. Apply gentle pressure to the bulb
while turning it to the left to remove.
394de123
License plate lamps
5 watt bulb
1. Insert a screwdriver into the slot and
press to the left (arrow); this
dislodges the lamp
2. Remove the lamp and replace the
bulb.
