Fig. 144: Measuring Bearing Play
Courtesy of BMW OF NORTH AMERICA, INC.
Conrod bearing clearance, refer to ENGINE - TECHNICAL DATA .
 Remove plastic thread.
 Coat crankshaft and bearing shells with oil.
 Install new conrod bolts and tighten down.
Tightening torque 11 24 1AZ. Refer to ENGINE - TIGHTENING TORQUES .
PISTON WITH RINGS AND PIN
11 25 530 REMOVING AND INSTALLING OR REPLACING ALL PISTONS (M52 / S52 / M52TU /
M54 / M56)
Special tools required:
