00 9 120
11 2 110
11 2 260
11 2 470
11 3 480
11 8 141
(engine removed) Remove cylinder head.
Removal:
Removal of pistons is described separately from installation. Assembly sequence for removal and installation is
different.
Remove oil pump. Refer to 11 41 000 REMOVING AND INSTALLING/REPLACING OIL PUMP
(M52TU / M54 / M56).
If oil pump and oil scraper are two parts: Remove oil scraper.
Fig. 145: Removing Oil Scraper
IMPORTANT: Re-install piston, connecting rod and bearing shells back in the same position
and in the same installation location. Connecting rods and bearing covers are
designated with the same pair number: do not mix them.
2006 BMW X5 30i
2004-2006 ENGINE Engine Mechanical - Repair Instructions - X3 & X5 (M54)
