Fig. 28: Releasing Banjo Bolt
Courtesy of BMW OF NORTH AMERICA, INC.
Replace O-ring on coolant pipe.
If necessary, replace sealing rings on banjo bolt (1).
Tightening torque of banjo bolt (1): 32 N.m.
Removal
Removal of cylinder head is described separately from installation.
Remove double VANOS adjustment unit, refer to 11 36 010 REMOVING AND INSTALLING OR
REPLACING DOUBLE VANOS ADJUSTMENT UNIT (M52TU / M54 / M56).
Remove camshafts with bearing strips, refer to 11 31 001 REPLACING CAMSHAFT (M52TU / M54 /
M56).
Release screw connection between timing case cover and cylinder head.
