Fig. 81: Removing Radial Seal
Courtesy of BMW OF NORTH AMERICA, INC.
Remove radial seal by tightening screw on special tool.
Coat sealing lips of new radial sealing ring with oil.
Using special tool 11 3 280 and centering screw, install new radial seal flush with timing case cover.
2006 BMW X5 30i
2004-2006 ENGINE Engine Mechanical - Repair Instructions - X3 & X5 (M54)
sábado, 2 de octubre de 2021 11:25:51 p. m. Page 86 © 2011 Mitchell Repair Information Company, LLC.
