Fig. 94: Unfastening Screw Connection On Reinforcement Plates
Courtesy of BMW OF NORTH AMERICA, INC.
Unfasten screw connection on main bearing.
NOTE: The reinforcement plates are not fitted on engines with gray cast iron engine
blocks or on engines with oil pumps integrated in oil scrapers.
2006 BMW X5 30i
2004-2006 ENGINE Engine Mechanical - Repair Instructions - X3 & X5 (M54)
sábado, 2 de octubre de 2021 11:25:51 p. m. Page 99 © 2011 Mitchell Repair Information Company, LLC.
