Replace defective light source.
Bulbs for flashing turn
indicators, front
RY10W / 12 V / 10 W
Bulbs for flashing turn
indicators, rear
RY10W / 12 V / 10 W
To protect the glass on the
new bulb against contamina-
tion, always use a clean, dry
cloth to hold it; do not touch
with bare fingers.
Fit bulb 1 in mirror housing by
turning it clockwise.
Locate lens in mirror housing
inner side first and close.
Fit the screw 1.
Replacing LED tail light
The LED tail light can only be
completely replaced.
Please contact a specialist
service facility for this pur-
pose, preferably an authorized
BMW Motorrad retailer.
Replacing the LED
headlight
with LED headlights
OE
LED headlights can be
completely replaced only.
Please contact a specialist
service facility for this purpose,
7
132
z Maintenance
ProCarManuals.com

BMW R 1200GS Adventure 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Compression Ratio	12.5:1
Fuel System	Electronic fuel injection
Final Drive	Shaft drive
Tire, Front	120/70 R19
Tire, Rear	170/60 R17
Width	980 mm
Height	1, 450 mm
Wheelbase	1, 510 mm
Weight, Wet	260 kg
Engine Type	Air/liquid-cooled four stroke flat twin engine
Power	125 hp (92 kW) at 7, 750 rpm
Torque	125 Nm at 6, 500 rpm
Transmission	6-speed
Frame	Two-section frame
Front Suspension	BMW Motorrad Telelever
Rear Suspension	BMW Motorrad Paralever
Front Brake	Dual disc brake, floating brake discs, diameter 305 mm, 4-piston calipers
Rear Brake	Single disc brake
Length	2255 mm
Seat Height	890 / 910 mm (Optional low seat: 860 / 880 mm)
Fuel Capacity	30 liters
