BMW R 1200RS 2016 User Manual

Topping up coolant
Open cap 1 of coolant expan-
sion tank and add coolant up
to specified level.
Coolant level lies between MIN
and MAX markings.
Close cap 1.
Tyres
Checking tire pressure
WARNING
Incorrect tire inflation pres-
sure
Poorer handling characteristic
of motorcycle, reduction of tire
service life
Ensure proper tire inflation
pressure.
WARNING
Automatic opening of verti-
cally installed valve cores at
high speeds.
Sudden loss of tyre inflation
pressure.
Use valve caps with rubber
sealing ring and screw on
firmly.
Park motorcycle, ensuring that
support surface is firm and
level.
Check tire pressures against
data below.
Tire pressure, front
36.3 psi (2.5 bar) (with tire
cold)
Tire pressure, rear
42.1 psi (2.9 bar) (with tire
cold)
If tire pressure is too low:
Correct tire pressure.
Wheel rims and tyres
Check wheel rims
Park motorcycle, ensuring that
support surface is firm and
level.
Subject wheel rims to visual
inspection for defects.
Have damaged rims checked
and, if necessary, replaced
by a specialist service facil-
8
123
z Maintenance
ProCarManuals.com

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
