BMW R 1200RS 2016 User Manual

ESA error
with Dynamic ESA
OE
shows yellow.
appears on the display.
Possible cause:
The ESA control unit has
detected an error. Motorcycle
damping is in this condition
very firm and riding is rather
uncomfortable - in particular on
rough roads.
Have the malfunction corrected
as soon as possible at an
authorized service facility,
preferably an authorized
BMW Motorrad Retailer.
The gear has not been
programmed
with Pro shift assistant
OE
The gear indicator flashes.
The gearshift assistant Pro
has no function.
Possible cause:
with Pro shift assistant
OE
The gear sensor has not been
fully programmed.
Engage idle N and let the en-
gine run for at least 10 sec-
onds while standing to program
the idle gear.
Shift through all gears by op-
erating the clutch and ride in
each engaged gear for at least
10 seconds.
The gear indicator stops flash-
ing after the gear sensor has
been successfully programmed.
After the gear sensor is fully
programmed, the gearshift as-
sistant Pro functions as de-
scribed ( 110).
If the programming process is
not successful, have the fault
eliminated at a specialist work-
shop, preferably an authorized
BMW Motorrad retailer.
Fuel down to reserve
lights up.
WARNING
Rough engine running or
switching off of the engine
due to a fuel shortage
Accident hazard, damage to cat-
alytic converter
Do not drive to the extent that
the fuel tank is completely
empty.
Possible cause:
At the most, the fuel tank still
contains the reserve fuel quantity.
3
39
z Displays
ProCarManuals.com

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
